Code: ZM8721000
ZIPP WHEEL - 1ZERO HITOP S TUBELESS DISC BRAKE 6-BOLT 29 FRONT 24SPOKES BOOST W/RS TORQUE CAPS STANDARD GRAPHIC A1
Zipp’s HiTOP S MTB wheelset melds high value with high performance for a simply better ride.With modern cross-country courses becoming rougher and more challenging, trail compliance is vital. No longer is it good enough for an XC wheelset to be stiff above all else. Instead, a wheelset should feel alive. The 1ZERO HiTOP S carbon rim’s design complies with the terrain thanks to Zipp's proprietary HiTOP Technology for carbon layup. The result is a light XC wheel that carries speed through all sections of the trail, rocks, roots, and ruts with the durability required for a trail bike with up to 130mm of travel. A compliant wheel provides more confidence. The 1ZERO HiTOP S features the dependable ZM 900 hubset.
FEATURES
HiTOP Technology produces proprietary rim layup to provide compliance and confidence when the trail gets rough
Low weight for effortless accelerations and climbing
Wide lips on top of the rim provide a smooth resting surface for the tire, reducing the chance of pinch flats after a rock hit
ZM 900 SL hub with 52 points of engagement
Standard or Torque Cap options on front hub
XD or Microspline drive-body options
TyreWiz sold separately
SPECIFICATIONS
Orientation (wheels): Front
Size (wheels): 29"
Rim construction: Carbon – Hookless
Tire compatibility: Tube-type or Tubeless tires
Rim depth: 21.2mm
Surface texture: Smooth
Brake compatibility: Disc (6-bolt)
Rim - inside width: 30mm
Rim profile: Asymmetrical
Rim finish: UD fiber, adhesive decals
Color (Decal): Standard
Nipple material: Aluminum
Nipple anti-rotation: Sapim Secure-Loc
Spoke type: CX-Sprint
Spoke count: 24
Spoke pattern: 2 Cross
Hub: ZM 900
Driver body type: n/a
Color (hub): Black
Axle type (Wheels): TA 15x110 Torque Caps (dia. 31mm)
Axle material: Aluminum front & rear
Bearings: Cartridge - Steel
Driver Mechanism: n/a
Driver body material: n/a
Max tire pressure: 50psi/3.45bar
Max recommended system weight: 286lbs/130kg
Spoke Length DS: 292mm
Spoke Length NDS: 288mm
Max outside width: 37.7mm
